2-spindle front drilling-/milling unit ER16 with coolant supply (internal)

Part Number 7.078.325
for 8 Machines
Ratio1:1
rpm at Inputmax. 8000 rpm
rpm at Outputmax. 8000 rpm
Torque at Outputmax. 13 Nm
Direction of Rotation
Scope of Deliverysupplied with wrench, excluding collets * Actual size inscribed on the tool
Additional CAD Files:
2D-View
3D-View
2D-View
3D-View / QR-Code

Upload to Smart Phone
